Description
Mil-Spec Circular Connector 19-Way Receptacle Kit
The MS3470A24-19S is a 19-way flanged receptacle circular connector kit with socket (female) contacts. The connector housing is black anodized aluminum.
MS3470A24-19S Kit Includes:
- (1) 19-Way Flanged Receptacle Connector Body.
- (19) Size 12 socket (female) contacts 23 A M39029/5-118
- (1) Insert/Removal Tool M81969/14-04
- (1) Cavity Plug MS27488-12-2 Quantity varies by part number.
Required Crimp Tooling:
- DMC Crimp Frame: AF8 requires TH1A
- DMC Turret: TH1A requires AF8
- Deutsch: HDT-48-00 all in 1 tool.
- Econo Tool: 18860 size, 12 contacts only.
Shrink Boots:
- Straight: 202K163-25-0
- 90°: 222K163-25-0
Shrink Boot Adapter:
- M85049/60-2G24A
Nut Plate:
- M85049/95-24B
