MIL-SPEC MS3470A-18-32S Flanged 32-Pin Receptacle Connector Kit

Description

Mil-Spec Circular Connector 32-Way Receptacle Kit

The MS3470A18-32S is a 32-way flanged receptacle circular connector kit with socket (female) contacts. The connector housing is black anodized aluminum.
MS3470A18-32S Kit Includes:

• (1) 32-Way Flanged Receptacle Connector Body.
• (32) Size 20 socket (female) contacts 7.5 A M39029/5-115
• (1) Insert/Removal Tool M81969/14-02
• (1) Cavity Plug MS27488-20-2 Quantity varies by part number.

Required Crimp Tooling:

• DMC Crimp Frame: AF8 requires TH1A
• DMC Turret: TH1A requires AF8
• DMC Positioner: K1S requires AFM8 (size 20 contacts only)
• Deutsch: HDT-48-00 all in 1 tool.
• Econo Tool: 18890 size, 20 contacts only.

Shrink Boots:

• Straight: 202K153-25-0
• 90°: 222K152-25-0

Shrink Boot Adapter:

• M85049/60-2G18A

Nut Plate:

• M85049/95-18A

Deutsch Autosport Variant (will not mate with Mil-Spec connectors):

• AS018-32SN
