MIL-SPEC MS3470A-14-12S Flanged 12-Pin Receptacle Connector Kit

Description

Mil-Spec Circular Connector 12-Way Receptacle Kit

The MS3470A14-12S is a 12-way flanged receptacle circular connector kit with socket (female) contacts. The connector housing is black anodized over aluminum.
This connector features a mixed arrangement, utilizing two different contact sizes.
MS3470A14-12S Kit Includes:

• (1) 12-Way Flanged Receptacle Connector Body.
• (4) Size 16 socket (female) contacts (20-16 AWG, 13 A each) M39029/5-116
• (8) Size 20 socket (female) contacts (22-18 AWG, 7.5 A each) M39029/5-115
• (1) Insert/Removal Tool M81969/14-02
• (1) Insert/Removal Tool M81969/14-04
• (1) Cavity Plug MS27488-20-2 Qty varies by part number.
• (1) Cavity Plug MS27488-16-2 Qty varies by part number.

Required crimp tooling:

• DMC Crimp Frame: M22520/1-01 (AF8) requires TH1A
• DMC Turret: M22520/1-02 (TH1A) requires AF8
• DMC Positioner: K1S requires AFM8 (size 20 contacts only)
• Deutsch: HDT-48-00 all-in-one tool.
• Econo Tool 18880 size 20 contacts only.
• Econo Tool 18890 size 16 contacts only.

Shrink Boots:

• Straight: 202K142-25-0
• 90°: 222K142-25-0

Shrink Boot Adapter:

• M85049/60-2G14A

Nut Plate:

• M85049/95-14A

Notes:

• Size 16 contacts can accept 14-AWG Tefzel wire if the stripped wire is perfect without stray conductor strands. The current rating remains the same at 13 amps each.
