Description
Jabsco PAR-Max Series water pressure pumps are simple, quiet, easy to maintain, and deliver hot or cold water just by turning on a tap. They are also versatile enough to produce a maximum flow or a simple trickle of water, as needed.
The PAR-Max 2.9 pump features one to three discharge ports with a flow rate of 2.9 gal/min (10.9 L/min). It has a built-in bypass module to dampen pressure pulsations and control unwanted pumping cycles and noise, eliminating the need for an accumulator tank if needed.
Features and Benefits:
- Co-molded diaphragm for strength and long life.
- Integrated, sealed pressure switch for on-demand operation.
- Can run dry without deteriorating.
- Mounting feet to dampen vibrations.
- Quick connect ports for easy installation, maintenance, and repair.
- Equipped with an integrated bypass module to reduce the pumping cycle and ensure a constant flow.
- Self-priming from 6 to 10′. (2 to 3 m)
- Complies with ISO 8846 MARINE. (protection against ignition)
- A screwless diaphragm eliminates the possibility of leakage.
- A special type of diaphragm allows dry running.
- Can eliminate the need for an accumulator tank.
- Includes quick-connect fittings for easy pump installation.
- Three-year warranty.
Specifications:
- Flow: 2.9 Gpm (11 L/min)
- Motor Cut-Out Pressure: 25 to 50 Psi (1.7 to 3.5 Bar)
- Fittings: Two 1/2” (13 mm) Straight Barbed Fittings
- Dimensions : 9” Long X 4.24” Wide X 4.75” High (22.9 Cm X 10.6 Cm X 12.1 Cm)
- Weight: 4 Lbs (1.8 Kg)
- Voltage: 12V
